Temperature & Humidity Sensor

1. Temperature Coefficient Type: NTC
2. Thermal Time Constant: 10s
3. Resistance  100kΩ
4. Tolerance: ±1%
5. Maximum Power Rating: 75mW
6. Maximum Operating Temperature: +150°C
7. Minimum Operating Temperature: -80°C
8. Dimensions(dia.): 2 mm
9. Length: 30mm
10. Application: Compensation, Control, Measurement, etc.

1. Temperature Coefficient Type: NTC
2. Thermal Time Constant: 32s
3. Resistance  10Ω
4. Tolerance: ±1%
5. Maximum Operating Temperature: +200°C
6. Minimum Operating Temperature: -55°C
7. Dimensions(dia.): 9 mm
8. Application: Compensation, Control, Measurement, etc.

NTC Thermistor temperature sensor module is low cost, small size module. It is very sensitive to ambient temperature. It is generally used to detect the temperature of the surrounding environment.

1. Detecting range: >120 degree
2. Analog and digital outputs
3. On-board potentiometer and indicators
4. 1% resistors to make this module more reliable and precise
5. Operating Voltage: 3.3V – 9V
6. Board Diameter: 40 mm.

1. Interface type: I2C
2. Working voltage: 1.8 – 6.0 V
3. Interface size: 4*2.54mm pitch
4. Humidity accuracy: typical ± 2%
5. Humidity resolution: 0.024%
6. Temperature accuracy: typical ± 0.3 ° C

1. Supply voltage: DC : 2.2 – 5.5V
2. Measuring range (humidity): 0 ~ 100% RH
3. Measuring range (temperature): -40 ~ + 120 ℃
4. Humidity accuracy: ± 2 % RH ( 25 ℃ )
5. Excellent long-term stability
6. SMD package is suitable for reflow soldering

1. Model: AM2301.
2. Supply voltage: 3.3 ~ 5.2 V DC.
3. Signal output form: Digital signal output.
4. Temperature measurement range: -40 ~ +80 ºC.
5. Temperature measurement precision: ± 0.5ºC
6. Humidity range: 10%~90%RH.
7. Humidity measurement precision: ±3%RH.

1. Voltage Rating: 5V
2. Humidity Range:0~99.9%RH
3. Measuring Range:-40~80℃
4. Resolution:0.1
5. Interface: Digital
6. Technology: Capacitive

1. Supply Voltage DC : 2.2 – 5.5V
2. Measuring Range (humidity) 0 ~ 100% RH
3. Fully calibrated and processed digital output, I²C protocol
4. Excellent long-term stability
5. Output Signal I2C signal

1. Sensor Output: Digital
2. Supply Voltage Max: 5V
3. Sensor Terminals: Through Hole
4. Response Time: 7s

1. Supply voltage (Vin): DC5V ± 5%.
2. Current Consumption: 2mA (MAX 5mA).
3. Operating temperature range: 0 to 60 ° C.
4. Humidity range: 95% RH (non condensing).
5. Humidity measuring range: 20 to 95% RH.
