Showing 49–68 of 68 results
-
Flight Controller & Accessories
OpenPilot CC3D EVO Flight Controller STM32 for RC Drone FPV Racing
-30%
Flight Controller & AccessoriesOpenPilot CC3D EVO Flight Controller STM32 for RC Drone FPV Racing
CC3D Flight Controller Hardware Features
Powerful STM32 32-bit microcontroller running at 90MIPs with 128KB Flash and 20KB RAM.
3-axis high-performance MEMs gyros and 3-axis high-performance MEMs accelerometer.
Tiny 36mmx36mm 4 layer PCB for superior electrical noise reduction and flight performance.
Software support for Windows, Mac, and Linux.
Direct high-speed USB support with no drivers required, a truly plug-and-play device.
Spektrum satellite receiver support.
Futaba S-BUS hardware support.
Innovative Flexi-port technology for superior port flexibility.
4Mbits on-board EEPROM for configuration storage.Note: Please don’t flash/Update the Default firmware. Updated or new firmware may cause a problem of connectivity with PC/Laptop.
Software for configuration: Openpilot
You can also use Software for configuration: Librepilot
Flexiport
CopterControl also offers the innovative Flexi-port which provides either I2C connectivity or a second serial port. Flexi-port gives CopterControl the flexibility to use either I2C
and a single serial port or dual serial ports, according to your connectivity needs.Superior user experience
OpenPilot has tried to make your experience with the CC3D as easy and trouble-free as possible. Naturally, for a high-end product, the hardware is complete; there is nothing to solder. The included RC harness allows you to connect any standard PWM receiver. All CopterControl boards are tested before shipping and come with a bootloader already flashed. A standard mini-USB cable (not included) is used to load the latest firmware and configure everything for your unique airframe.The OpenPilot project, whist still young, it trying to make Open Source much more user-friendly. OpenPilot software is designed to be used by everybody! All major operating systems are supported and install packages are provided. The software is all Free software under the GPLv3 license and not only are you welcome to hack it, but we encourage it!
Sensors and Components
3-axis Gupports several common RC inputs: 6 PWM channels, combined PPM, Spektrum/JR DSM2,
Supports several common RC inputs: 6 PWM channels, combined PPM, Spektrum/JR DSM2, DSMJ, DSMX satellites, and Futaba S.Bus receivers.
Simultaneous support for multiple receivers.
ReceiverPort functions (configurable): 6 PWM input channels or combined PPM stream, 4 PWM output channels
MainPort functions (configurable): serial telemetry (default), GPS, S.Bus, Spektrum/JR satellites
FlexiPort (configurable): serial telemetry, GPS, Spektrum/JR satellites, or I2C peripherals (under development)
10 PWM outputs to servos or ESC’s, or for camera stabilization
Camera stabilization: supports up to 3-axis camera mounts with stabilization and manual control from any of configured receivers.
Onboard USB connectivity for easy configuration.
USB and serial telemetry and configuration
Supported by powerful OpenPilot GCS
4 Mbit onboard memory
3C Quaternion based complementary filter running at 500HzPackage included:
1 x CC3D EVO Flight Controller And CablesSKU: n/a -
Drone Parts, Flight Controller & Accessories
Pixhawk 2.4.8 Drone Flight Controller PX4 32 Bit Autopilot – Good Quality
-49%
Drone Parts, Flight Controller & AccessoriesPixhawk 2.4.8 Drone Flight Controller PX4 32 Bit Autopilot – Good Quality
- Supply Voltage: 7V.
- Processor: 32 Bit Cortex M4 Core
- Bus interface (UART, I2C, SPI, CAN).
- Firmware: Mission planner.
- Sensors: Gyrometer, Accelerometer, Barometer & Magnetometer
- Micro SD card to record flight data.
SKU: n/a -
Flight Controller & Accessories
Pixhawk 2.4.8 Drone Flight Controller PX4 32 Bit Autopilot – Good Quality
-57%
Flight Controller & AccessoriesPixhawk 2.4.8 Drone Flight Controller PX4 32 Bit Autopilot – Good Quality
- Supply Voltage: 7V.
- Processor: 32 Bit Cortex M4 Core
- Bus interface (UART, I2C, SPI, CAN).
- Firmware: Mission planner.
- Sensors: Gyrometer, Accelerometer, Barometer & Magnetometer
- Micro SD card to record flight data.
SKU: n/a -
Flight Controller & Accessories
Pixhawk 2.4.8 PX4 32 Bit Flight Controller with Safety Switch and Buzzer for Drone High Quality
-41%
Flight Controller & AccessoriesPixhawk 2.4.8 PX4 32 Bit Flight Controller with Safety Switch and Buzzer for Drone High Quality
Characteristics:
- Compatible with Alexmos2.2 or firmware below, compatible with the newest firmware BruGi_050 German, standard Russian2.2 firmwareTips
- A new generation of strong input control 32-bit processor, a circuit board with PX4FMU + PX4IO
Specifications:
- 32-bit Pixhawk PX4 Autopilot Open Code Flight Controller V2.4.8
- 2 bit 1.32 STM32F427 flash Cortex M4, with the floating-point hardware processing unit
- 2 main frequency: 256 K, RAM 168 MHZ
- 32-bit processor STM32F103 backup co
Sensors:
- L3GD20 3-axis 16-bit digital gyroscope
- LSM303D 14/3 Axis Accelerometer Magnetometer
- MPU6000 6-axis accelerometer / magnetometer
- MS5611 high precision barometer
Interface:
- 5 UART 1 High Voltage compatible, 2 with hardware flow control
- 2 CAN
- DSM / DSM-X Spektrum compatible satellite receiver input
- SBUS input and output compatible
- PPM signal input
- RSSI (PWM or input voltage)
- I2C
- SPI
- 3.3 and 6.6 VADC inputs
- external US MICRO
Package includes:
1 X 2.4.8 Pixhawk main control with shell
1 X Safety switch
1 X Buzzer
1 X Memory Card
Connection Wire
SKU: n/a -
DRONE COMBO, Flight Controller & Accessories
Pixhawk Cube Orange+ with ADS-B Carrier Board
Pixhawk Cube orange+ flight controller with ADS-B Carrier Board
Advanced Sensor Suite for Precision and Stability
To begin with, this product offers a comprehensive suite of sensors, including an accelerometer, gyroscope, compass, and barometric pressure sensor.
These sensors, work together seamlessly to provide accurate and reliable data, ensuring precision, stability across various applications.
SKU: n/a -
Drone Parts, Flight Controller & Accessories
Pixhawk Cube Orange+ with ADS-B Carrier Board
- Sensors: Accelerometer, Gyroscope, Compass, Barometric Pressure Sensor
- Power input voltage/rated input current: 4.1-5.7 V / 2.5 A
- Power-rated output/input power: 14 W
- USB port input voltage/rated input current: 4-5.7 V / 250 mA
- Servo rail input voltage: 3.3 V / 5 V
- Not waterproof. External waterproof protection is needed
- Operation Temperature: -10 °C / 55 °C
- Cube Orange+ Housing Material: CNC Aluminum Allows
- ADSB Carrier Board Housing Material: ABS Molding
SKU: n/a -
Drone Accessories, Flight Controller & Accessories
Pixhawk I2C Port Expand Board with Cable
- Package Weight: 5 gm
- Number of Ports: 5.
- Board Dimensions: 33 x 12 x 6 mm(LxWxH)
- Net Weight: 3g
- Brand new and high quality
- The I2C splitter expands the I2C port to allow up to four additional peripherals to connect to Pixhawk.
SKU: n/a -
-
DRONE COMBO, Drone Kit, Drone Motor, Drone Parts, Drone Transmitter and Receiver, Flight Controller & Accessories
Power Distribution Board 200A / PDB Capable of 200A Current Carrying Capacity for 14S LiPo Battery / 5V/12V BEC/Four XT90 Connectors/Current Measurement Sensor (up to 200A)
-5%
DRONE COMBO, Drone Kit, Drone Motor, Drone Parts, Drone Transmitter and Receiver, Flight Controller & AccessoriesPower Distribution Board 200A / PDB Capable of 200A Current Carrying Capacity for 14S LiPo Battery / 5V/12V BEC/Four XT90 Connectors/Current Measurement Sensor (up to 200A)
- Capable of handling high current (up to 200A), Anti-spark soft switching for inductive loads
- Input voltage up to 15-60V (12S), 4x XT90 connectors (50A each for ESC with motor)
- Analog battery voltage and current sensors output for flight controllers and robotic applications
- DC-DC converter from 15-60V input (up to 12S battery) to 5V 5A output, DC-DC converter from 15-48 V input (up to 12S battery) to 12V 5A output
- 5V and 12V power output terminals (standard 2.54mm/0.1″ connectors), Power output for flight controller (for eg., Pixhawk, Cube Orange)
SKU: n/a -
Flight Controller & Accessories
Radiolink Mini PIX Flight Controller Mini Pixhawk Controller Mini Pix APM Flight Controller V1.2 FC for 3-6 Axis FPV
-20%
Flight Controller & AccessoriesRadiolink Mini PIX Flight Controller Mini Pixhawk Controller Mini Pix APM Flight Controller V1.2 FC for 3-6 Axis FPV
Description:
The Radiolink independently developed the Mini PIX Flight Controller, and the enclosure uses closed protection for the barometer to reduce airflow interference during the movement and reduce vibration. At the same time, the software algorithm optimizes the air pressure to maintain the PIXHAWK complete function, which is easy to set up.
Specifications:
- Connector Port: JST GH connector
- Receiver In: PPM/SBUS
- Transmitter: 6 Oneshot/PWM
- USB Voltage: 5v+-0.3v
- Work Voltage: 5.1v
- Work Temperature Range: -40~80°
- Size: 3.9*3.9*1.4cm/1.54*1.54*0.47in
- Weight: 15/0.034Lb
SKU: n/a -
Flight Controller & Accessories
Radiolink Pixhawk Flight controller board
Radiolink Has optimised its pixhawk flight controller PCB layout and height hold with the barometer sensor MS5611. It is a highly stable flight controller that comes from the radiolink. This controller provides more stable flight performance even at high speed. It integrated the newest 32-bit chip technology and high-end sensors, this is absolutely one of the best flight controllers for quadcopters.
Feature:
- Multi-sound buzzer interface support.
- Multiple flight modes, support for self-stability, height-set, hover, sports, freestyle, circling, following, return, guidance, automatic, and all-powerful.
- Abundant connectivity options for additional peripherals (GPS, I2C, SPI).
- 14 PWM / servo outputs (8 with failsafe and manual override, 6 auxiliary, high-power compatible).
- Providing a multi-sound buzzer interface.
- Multiple flight mode switches freely, Helicopter, Fixed-wing, Multi-rotor, Model Car.
- All interfaces are fully tested and accurately detected by an automatic detection system, avoiding bad interfaces leading to flight control installation unsuccessfully.
- Support DSM Spektrum receiver.
- Advanced 32-bit CortexM4 ARM high-performance processor, and 32-bit STM32STMF100 failsafe co-processor.
- Equipped with buzzer, 4G memory card, safety switch and power module.
TECHNICAL Processor 32bit 32F427 ARM Cortex M4 Core + FPU (floating point unit) Frequency 168 MHZ Memory Size 2 MB Flash RAM Size 256 KB Sensor ST Micro L3GD20H 16 bit gyroscope FLIGHT CONTROLLER Sensors MEAS MS5611 barometer Hardware Details Barometer sensor MS5611 Three-axis digital gyroscope IST8310 triaxial accelerometer(E-compass) IST8310 Six-axis accelerometer(Gyro) MPU6000 FRAM FM25V02
(256Kb)All Functions Automation Software Testing System Have SKU: n/a -
Drone Parts, Flight Controller & Accessories
RPLiDAR S2 Low Cost 360 Degree Laser Range Scanner – 30M Range(Ethernet PORT)
-12%
Drone Parts, Flight Controller & AccessoriesRPLiDAR S2 Low Cost 360 Degree Laser Range Scanner – 30M Range(Ethernet PORT)
RPLIDAR RPLiDAR S2 Low Cost 360 Degree Laser Range Scanner Application Scenarios Works well both in indoor and outdoor environment.reliable Distance Range On White Objects: 30m (White light-diffused surface) Blind Range 0.05m Sample Rate 32Khz Sample Frequency 10Hz typical Angle resolution 0.12′ Temperature Range -10″C-5D’C Range Accuracy t:30mm Distance Resolution 13mm Band Rate 1M System Voltage 5V Power Consumption > 2W Proof Level IP65 SKU: n/a -
Drone Accessories, Flight Controller & Accessories
SP RACING F3 FC Replacement Accessories Set
Accessories compatible with SP RACING F3 Flight Controller Module
High-quality cable and connectors.
1 x 3*8 Burg connector(Straight)
1 x 3*8 Burg connector(Right-angle)
1 x 1*10 Burg Connector(Straight)
2 x 2pt cable
2 x 4pt cable
2 x 8pt cableSKU: n/a -
Flight Controller & Accessories
SpeedyBee SB-F4V3-50-STACK
You will get an STM32F405 FC (better than F411), onboard 4-level battery life indicator, 4GB Blackbox SD card slot for your flight logs, 4 groups of LED strip pads, complete with a DJI plug for your digital quad, and built-in Bluetooth
for wireless configuration on the SpeedyBee app. Don’t forget about the powerful 50A 4-in-1 ESC, built with TVS
protective diode + Japan-made TDK SMT capacitors + external 1500uF low ESR capacitor, everything is for durable build and smooth flight.
Features:
- Built-in barometer for accurate height calculation
- SD Card slot can support up to 4GB Blackbox data
- Dedicated DJI Air Unit connector for a quick digital build
- 9V 2A + 5V 2A individual BECs
- 4 x UARTs for your receiver + VTX + camera + GPS.
- Power your GPS with a USB cable – no battery needed
SKU: n/a -
Flight Controller & Accessories, FPV Antennas and Trans-Receivers
TBS Triumph Antenna FPV With SMA Male Connector-(Copy)
-33%
Flight Controller & Accessories, FPV Antennas and Trans-ReceiversTBS Triumph Antenna FPV With SMA Male Connector-(Copy)
- Connector: Male SMA.
- Polarization – RHCP
- Frequency Range: 5500 – 6000 MHz
- Gain: 1.26 dBic
- Axial Ratio: 0.74
- Antenna Length(mm): 82
Note: This is not an original TBS product, but a high-quality clone of one.
SKU: n/a
